Industrial Sponge

Industrial Sponge & Cellular Polymer Solutions: Technical Specifications & OEM Fabrication



Industrial sponge materials require strict control over cellular morphology and polymer chemistry to perform under mechanical stress, thermal cycling, and environmental exposure. Our engineered foam range includes EPDM, Neoprene (CR), Nitrile (NBR), Silicone, and EVA polymers, available in both closed-cell and open-cell configurations.


First 123 Last 1/3


Technical Specifications



Sponge Material

Cell Structure

Key Performance

Density

Operating Temperature

Other Technical Properties / Standards

EPDM Sponge

Closed-cell

Excellent resistance to ozone, UV radiation and weathering

110–180 kg/m³

-40°C to +125°C

Water absorption < 5% per ASTM D1056

Neoprene (CR) Sponge

Closed-cell

Balanced resistance to oil, flame and weathering

130–220 kg/m³

-35°C to +110°C

Self-extinguishing per FMVSS 302

Silicone (VMQ) Sponge

Closed-cell

High-temperature stability and low compression set

200–350 kg/m³

-60°C to +200°C continuous; up to +260°C intermittent

Complies with FDA 21 CFR 177.2600

NBR (Nitrile) Sponge

Closed-cell

High resistance to petroleum-based oils, fuels and aliphatic hydrocarbons

140–200 kg/m³

-30°C to +100°C

Suitable for oil- and fuel-contact applications

Polyurethane & EPDM Sponge

Open-cell

High breathability, air permeability and fluid absorption

—

—

Porosity: 10–80 PPI; compression recovery >90%



Product Type



Polymer Series

Structure

Primary Advantage

Typical Industrial Use

ASTM D1056 Grade

EPDM-400

Closed-Cell

UV, Ozone & Oxidation Resistance

HVAC Enclosures, Outdoor Cabinet Seals

2A2 / 2A3

CR-200

Closed-Cell

Flame Retardant & Moderate Oil Resistance

Battery Pack Spacers, Transit Seals

RE41 / SCE41

SIL-300

Closed-Cell

Extreme Temperature & Ozone Stability

Aerospace Gaskets, Lighting Fixtures

2C4 / 2C5

NBR-100

Closed-Cell

Hydrocarbon & Oil Fuel Resistance

Hydraulic Fluid Barriers, Engine Gaskets

2B2 / 2B3

EVA-50

Closed-Cell / Cross-linked

Rigid Cushioning & Shock Absorption

Protective Packaging, Sports Padding

---



Oil Absorbent Industrial Sponge



Application Scenarios

HVAC & Refrigeration Units: Closed-cell EPDM and NBR sponge sheets applied as internal duct liners and compressor vibration isolation pads to prevent thermal bridging and condensation.


Electrical Enclosures & Telecom Cabinets: Die-cut EPDM and Neoprene gaskets providing IP65/IP67 ingress protection against dust and driving rain.


Automotive & Commercial Vehicles: Neoprene and EPDM sponge extrusions and molded pads used for door trim sealing, dashboard anti-rattle strips, and wiring harness protection.


Industrial Equipment & Machinery: High-density silicone sponge strips serving as thermal insulation barriers in high-temperature packaging machinery and heat-sealing bars.




OEM & Processing


Production capabilities support custom fabrication from master buns and continuous rolls to match exact equipment assembly specifications.

01/

Adhesive Lamination

Application of single-sided or double-sided pressure-sensitive adhesives (PSA) including acrylic, rubber-based, and fiber-reinforced transfer tapes.

02/

Precision Die-Cutting & Kiss-Cutting

High-speed hydraulic and rotary die-cutting for complex gasket profiles with tolerances within +/- 0.5 mm.

03/

CNC Profile Cutting & Slitting

In-house automated vertical and horizontal saws producing continuous rolls, square-edge strips, and custom-beveled profiles.

04/

Custom Packaging

Bulk palletized rolls, interleaved sheet packs, and kiss-cut roll formats designed for automated pick-and-place assembly lines.



Manufacturing & QC

Raw polymer compounding is executed using internal Banbury mixers, followed by continuous steam-autoclave vulcanization or vertical foaming ovens. Quality control protocols adhere to ISO 9001 standards.

Density Testing

Gravimetric measurement of foam mass per unit volume per ASTM D3575.

01

Compression Set Verification

Mechanical loading tests measuring permanent deformation after 50% compression at 70°C for 22 hours per ASTM D395.

02

Tensile Strength & Elongation

Universal mechanical testing machines measuring breaking force per ASTM D412.

03

Dimensional & Thickness Inspection

Non-contact optical and digital gauge verification across entire roll lengths to ensure uniformity.

04

Compliance Documentation

Material Test Reports (MTR) provided with every production lot, verifying RoHS, REACH, and UL94 compliance.

05



FAQ



Q: What is the difference between closed-cell and open-cell sponge materials?

A: Closed-cell sponge features individual, gas-tight cells that prevent the passage of air, water, and moisture, making it ideal for sealing and gasketing. Open-cell sponge contains interconnected pores that allow air and fluid permeability, suited for absorption, filtration, and ventilation applications.

Q: How do I select the correct material for outdoor UV and ozone exposure?

A: EPDM (Ethylene Propylene Diene Monomer) and Silicone (VMQ) exhibit exceptional inherent resistance to ozone, UV degradation, and extreme weathering without cracking or hardening over prolonged service intervals.

Q: What adhesive backing options are available for sponge strips?

A: Standard options include high-tack acrylic adhesives for permanent high-temperature bonding and rubber-based adhesives for rapid initial tack on low-surface-energy plastics. Fiber reinforcement scrims can be added to prevent stretching during installation.

Q: Can you supply custom die-cut gaskets with specific dimensional tolerances?

A: Yes. Production utilizes CNC flatbed and rotary die-cutting machinery capable of maintaining dimensional tolerances down to +/- 0.3 mm based on CAD drawings (.dxf/.dwg).

Q: What are the standard lead times for bulk roll and custom fabrication orders?

A: Standard catalog rolls ship within 5 to 7 business days. Custom die-cut gaskets, adhesive laminations, and specialized polymer formulations require 12 to 18 business days depending on tooling setup and volume.

Q: What quality and environmental compliance documentation accompanies shipments?

A: Each dispatch includes a Certificate of Analysis (CoA) detailing density, tensile strength, and compression deflection values, alongside full documentation verifying compliance with RoHS, REACH, and ASTM standards.

As one of the leading industrial sponge manufacturers and suppliers in China, we warmly welcome you to buy discount industrial sponge from our factory. All customized products are with high quality and low price. For quotation, contact us now.
